Fire Suppression Units

CFF 800

The CFF 800 is one of our patented Dual Agent fire suppression systems. The CFF 800 utilizes a combination of CF-33 Dry Chemical and FM-200 Clean Agent gas to offer a 20% advantage over a similar sized dry chemical only unit. Each unit is built standard with a 155°F upright sprinkler head, Nason low pressure switch (for system monitoring or as a power shutoff), and an easy to read pressure gauge. Custom options for all of our units are available upon request.

The Cease Fire® System Unit CFF 800 must be hung vertically with the sprinkler deflector pointed downward. The unit is to be used in areas where the temperature falls between 32° degrees and 120° degrees Fahrenheit (0° to 48.89° degrees Celsius). The unit is to be mounted or attached to a secure ceiling, for example; wood, metal, or concrete. Insure there are no obstructions to the free flow operations of the sprinkler head and disbursement of the extinguishment within the enclosure.
Do not mount on suspended ceiling or loose tiles.

The Cease Fire® Unit is self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155ºF (68ºC). Alternative temperature settings are available upon request. The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designated at the time of purchase. When the temperature rise to activate the Cease Fire® unit, the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.

CFF 800LP

The CFF 800LP was the next logical step for our Dual Agent line of units. Allowing the unit to be installed horizontally, for low ceiling applciations, without sacrificing the unparralleled performance of the traditional CFF 800. The CFF 800LP takes up a mear 7.25" compared to 15" needed for the vertically installed CFF 800.

The Cease Fire® System Unit CFF 800LP must be hung horizontally with the sprinkler deflector pointed downward. The unit is to be used in areas where the temperature falls between 32° degrees and 120° degrees Fahrenheit (0° to 48.89° degrees Celsius). The unit is to be mounted or attached to a secure ceiling, for example; wood, metal, or concrete. Insure there are no obstructions to the free flow operations of the sprinkler head and disbursement of the extinguishment within the enclosure.
Do not mount on suspended ceiling or loose tiles.

The Cease Fire® Unit is self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155ºF (68ºC). The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designated at the time of purchase. When the temperature rise to activate the Cease Fire® unit, the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.

CFF 1330LP

The CFF 1330LP, formerly known as the CFF 960LP, is the largest of our Dual Agent line. Able to protect up to an 11'x11'x11' space per unit. The CFF 1330LP is ideal for low ceiling / high hazard applications where a high volume of dry chemical agent is desired.

Each Cease Fire® Unit is self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155ºF (68ºC). Other activation temperatures are available, such as 135, 175, 200, 286 or 500°F. Higher temperature custom application systems have a maximum reaction temperature of 1,800°F. The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designated at the time of purchase. When the temperature rise to activate the Cease Fire® unit, the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.

CFP 88LP

The CFP 88LP, formerly know as the CFP 80LP, is the smallest of our Dry Chemcial units. Designed to be installed horizontally, and to protect any space that is 4'x4'x5' or smaller. The new design of the CFP 88LP also allows for an alternative coverage of 3.33'x3.33'x8' for a more flexible coverage overall.Ideal for cabinet enclosures, 3D printers or any other small hard to reach location. Our CF-33 dry chemical agent is non-corrosive, non-conductive & non-toxic, making it a safe option for nearly any application.

Each Cease Fire® Unit is self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155ºF (68ºC). Other activation temperatures are available, such as 135, 175, 200, 286 or 500°F. Higher temperature custom application systems have a maximum reaction temperature of 1,800°F. The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designated at the time of purchase. When the temperature rise to activate the Cease Fire® unit, the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.

CFP 96

The CFP 96 is the vertically installed counterpart to the CFP 80LP.   It is designed to be installed vertically and protect any space that is 4'x4'x6' or smaller.  Ideal for cabinet enclosures, 3D printers, medical and science fume hoods, or any other small hard to reach location.  Our CF-33 dry chemical agent is non-corrosive, non-conductive & non-toxic, making it a safe option for nearly any application.

The Cease Fire® Unit is self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155ºF (68ºC). The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designated at the time of purchase. When the temperature rise to activate the Cease Fire® unit, the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.

CFP 640

The CFP 640 bridges the difficult gap between small spaces and mid-sized spaces.  It is a Dry Chemical unit designed to be installed vertically.  It protects any space 8' x 8' x 10' or smaller.  Great for modular spaces, portable shelters, storage rooms, any space that requires automatic fire suppression, or as part of a networked system for applications eight foot wide but longer in length, like a conex box. Our CF-33 dry chemical agent is non-corrosive, non-conductive & non-toxic, making it a safe option for nearly any application.

The Cease Fire® Unit is self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155ºF (68ºC). The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designated at the time of purchase. When the temperature rise to activate the Cease Fire® unit, the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.

CFP 640LP

The CFP 640LP bridges the difficult gap between small spaces and mid-sized spaces.  It has all the same attributes as the CFP 640, but uses a low profile mounting system.  Designed to be installed horizontally, and to protect any space that is 8' x 8' x 9' or smaller.  Great for modular structures, portable shelters, storage rooms, quiet spaces, as well as spaces with height restrictions, challenges, or bottlenecks.  Our CF-33 dry chemical agent is non-corrosive, non-conductive & non-toxic, making it a safe option for nearly any application.

The Cease Fire® Unit is self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155ºF (68ºC). The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designated at the time of purchase. When the temperature rise to activate the Cease Fire® unit, the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.

CFP 1300LP

The first of all the Low Profile units.  The CFP 1300LP, formerly known as the CFP 1100LP, is designed to be installed horizontally, and to protect any space that is 10' x 10' x 13' or smaller.  With its larger coverage and low profile design the CFP 1300LP is a great solution for any application with a height or space restriction.  Portable spaces, Conex box spaces, storage areas, conference rooms, grow rooms, lithium-ion battery applications and more.  Any application where there is an install challenge do to a lack of vertical space the CFP1300LP is used.  Our CF-33 dry chemical agent is non-corrosive, non-conductive & non-toxic, making it a safe option for nearly any application.

Each Cease Fire® Unit is self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155ºF (68ºC). Other activation temperatures are available, such as 135, 175, 200, 286 or 500°F. Higher temperature custom application systems have a maximum reaction temperature of 1,800°F. The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designated at the time of purchase. When the temperature rise to activate the Cease Fire® unit, the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.

CFP 1300

The CFP 1300 is an all-purpose easy to install unit that addresses up to 10’x10’x13’.  Standard building offices, conference rooms, storage areas, grow rooms, lithium-ion battery applications, any space where there is a water restriction or lack of water capacity the CFP 1300 is used.  Our CF-33 dry chemical agent is non-corrosive, non-conductive & non-toxic, making it a safe option for nearly any application.

The Cease Fire® Unit is self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155ºF (68ºC). The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designated at the time of purchase. When the temperature rise to activate the Cease Fire® unit, the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.

CFP 1700

The CFP 1700 is a great, all-purpose, easy to install unit.  The CFP 1700 addresses up to 11.50’x11.50’x13’.  Offices, conference rooms, storage areas, grow rooms, industrial spaces, any space where there is a water restriction or lack of water capacity the CFP 1700 is used.  Our CF-33 dry chemical agent is non-corrosive, non-conductive & non-toxic, making it a safe option for nearly any application.

The Cease Fire® Unit is self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155ºF (68ºC). The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designated at the time of purchase. When the temperature rise to activate the Cease Fire® unit, the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.

CFP 3375

The CFP 3375 is the second largest of our Dry Chemical units.  With it’s significant coverage reach this system can address much larger spaces.  It is installed vertically and covers 15’x15’x15’.  Larger and/or taller building offices, warehouses, work spaces, storage areas, industrial spaces, any space where there is a water restriction or lack of water capacity the CFP 3375 is used.  Our CF-33 dry chemical agent is non-corrosive, non-conductive & non-toxic, making it a safe option for nearly any application.

The Cease Fire® Unit is self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155ºF (68ºC). The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designated at the time of purchase. When the temperature rise to activate the Cease Fire® unit, the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.

CFP 3375LP

It’s finally arrived.  The CFP 3375LP.  After years of waiting, the next unit in the CFP line is here.  Designed to be installed horizontally, and to protect any space that is 15 x 15' x 15' or smaller.  With its even larger coverage and low profile design the CFP 3375LP is a money and time saving solution for any application with a height or space restriction.  Portable spaces, Conex box spaces, storage areas, conference rooms, grow rooms, lithium-ion battery applications and more.  Any application where there is an install challenge do to a lack of vertical space the CFP 3375LP is used.
