CFP 128LPCease Fire
The CFP 128LP is new to our line up of our Dry Chemcial units. Designed to be installed horizontally, and to protect any space that is 4'x4'x8' or smaller. Ideal for office pods, server closets, small electrical rooms, 3D printers or any other small hard to reach location. Our CF-33 dry chemical agent is non-corrosive, non-conductive & non-toxic, making it a safe option for nearly any application.
The Cease Fire® Units are self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155ºF (68ºC). The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designated at the time of purchase. Alternative sprinkler head options are available upon request. Ranging from 135, 175, 200, 286 or 500°F. When the temperature rises to activate the Cease Fire® unit, the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.
Suppressing Agents: CF-33 ABC Dry Chemical Blend
Maximum Total Flood Volume: 4’x4’x8’ = 128 Cu. Ft.
1.219m x 1.219m x 2.438m = 3.625 Cubic Meters
Reach Coverage Area: 4’x 4’ = 16 Sq. Ft.
1.219m x 1.219m = 2.438 Square Meters
Temperature Rating/Validation: -20°F to 120°F / -28.89°C to 49°C
Cylinder: Worthington Cylinder 4.25
Diameter: 4.25” / 10.795cm
Length: 12.77” + 3.12” Coupling Assembly / 32.436cm + 8.60cm
Unit Weight: 10.25 lbs. / 4.649 kg
Ship Weight: 12.5 lbs. / 5.669 kg
Operating Pressure: 175 psi / 1207 kPa
Propellant: High Purity Compressed Dry Nitrogen
Standard System Activation: 155° Fahrenheit / 68.3° Celsius
