PAD 200-PHD Photoelectric Smoke/Heat DetectorPotter
The PAD200-PHD is a listed Analog Addressable smoke sensor and a rate of rise and/or fixed temperature heat sensor compatible with fire alarm control panels that utilize the Potter Addressable Device (PAD) protocol.
The PAD200-PHD is a low profile smoke/heat sensor with a wide sensitivity range. The heat sensing portion utilizes a proven thermistor for accurate and reliable heat detection. The sensor and base (not included) are made of a durable plastic in an off-white color to blend in with the ceiling.
Operating Voltage 24 VDC
Detector Current Draw 300
Alarm indicator 1
Alarm set-point range for Smoke 1.1% - 3.5%
Alarm set-point for Heat 135°F
Installation temperature range 32°F to 120°F (0°C to 49°C)
Operating relative humidity range 0% to 93% (Non-condensing)
Start-up time Max. 1 sec.
Maximum number of addresses per loop 127
Maximum number of lighted indicators in alarm per loop 30
Coloreggshell White Weight (without base) 3.6 oz
Dimensions (without base) Height: 1.94 in (49mm)
Diameter 3.93 in (100mm)
